Audio Speakers - Premium
1 – AUDIO, SPEAKER, ASSEMBLY, 200MM
1004833-11-A
Front door speaker, contains 1004833-03-A speaker and 1004833-04-A spacer.
2 – AUDIO, SPEAKER, MID WOOFER SPEAKER 160MM
1004833-02-A
use on Rear Door
3 – AUDIO, SPEAKER, MID RANGE, 80MM
1004833-01-A
use on dash and Tailgate
4 – BLT,TPG,TRX,BTN,ST4.2×1.4-20[SS]-S-01
1014049-00-B
Use on item #5
5 – AUDIO, SPEAKER, TWEETER, 30MM
1004833-00-A
use on A-Pillar
6 – SUBWOOFER SPEAKER ASSEMBLY
1042544-00-B
use on vehicles manufactured on or after November 2nd, 2014
7 – AUDIO, SPEAKER, ASSEMBLY, SUBWOOFER
1004833-05-C
use on vehicles manufactured before November 2nd, 2014
8 – GROM – SCREW – M5 SELF TAP – 0.8 – 2.5 – 7MM SQ
1003209-00-A
Use on doors. Order in quantities of 100; minimum order: 100.
9 – SCREW, TORX, M5X16, ZINC NICKEL
1012629-00-B
use on item #3 and 4
10 – SCR,M4.8-2.82X16MM,WH,HEX,POLYFAST.A
1016812-00-A
Use to install PN 1004833-11-A
11 – AUDIO, AMPLIFIER, EXTERNAL, PREMIUM
1004833-10-A
12 – BOLT – HEX – M6X25[9.8] – M – S – 02
1006551-00-B
use to mount Subwoofer to trunk. ok to use A.
